Model：24128CA/W33
Old Model：
Brand：FM
Type：Spherical Roller Bearing
d：140
D：225
B：85.0
TEL：86-15961781062 Online Service
| Dimansion mm | |
| d | 140 |
| D | 225 |
| B | 85.0 |
| b | 8.3 |
| k | 4.5 |
| r 1,2 | 2.1 |
| Load ratings kN | |
| Cr | 673.0 |
| Cor | 1160.0 |
| Limiting Speed r/min | |
| Grease | 850 |
| Oil | 1100 |
| Designation | |
| Cylindrical Bore | 24128CA/W33 |
| Taper Bore | 24128CAK/W33 |
| Fitting dimansion mm | |
| d a max | 152 |
| D a max | 213 |
| r a max | 2.0 |
| Weight(kg) (Taper Bore) | |
| Weight(kg) (Taper Bore) | 13.5 |
Wuxi Bosu Transmission Equipment Co., Ltd.specializes in selling FM-24128CA/W33-Spherical Roller Bearing，Relevant information of FM-24128CA/W33-Spherical Roller Bearing includes： Designation: 24128CA/W33 d:140 D:225 B:85.0 Brand:FM Type:Spherical Roller Bearing ，Want to know more about FM-24128CA/W33-Spherical Roller Bearing You can consult online or call the hotline, we will provide you with detailed service.
FM-24128CA/W33-Spherical Roller Bearing is widely used.FM-24128CA/W33-Spherical Roller Bearing is mainly used in construction machinery, machine tools, automobiles, metallurgy, mines, petroleum, machinery, electric power, railways and other industries. The price of FM-24128CA/W33-Spherical Roller Bearing sold by the company is reasonable, the quality is guaranteed, the service in all aspects is provided, and the customer's demand is satisfied.
