Model：22336CA
Old Model：
Brand：FM
Type：Spherical Roller Bearing
d：180
D：380
B：126.0
TEL：86-15961781062 Online Service
| Dimansion mm | |
| d | 180 |
| D | 380 |
| B | 126.0 |
| b | |
| k | |
| r 1,2 | 4.0 |
| Load ratings kN | |
| Cr | 1730.0 |
| Cor | 2450.0 |
| Limiting Speed r/min | |
| Grease | 900 |
| Oil | 1200 |
| Designation | |
| Cylindrical Bore | 22336CA |
| Taper Bore | 22336CAK |
| Fitting dimansion mm | |
| d a max | 198 |
| D a max | 362 |
| r a max | 3.0 |
| Weight(kg) (Taper Bore) | |
| Weight(kg) (Taper Bore) | 72.2 |
Wuxi Bosu Transmission Equipment Co., Ltd.specializes in selling FM-22336CA-Spherical Roller Bearing，Relevant information of FM-22336CA-Spherical Roller Bearing includes： Designation: 22336CA d:180 D:380 B:126.0 Brand:FM Type:Spherical Roller Bearing ，Want to know more about FM-22336CA-Spherical Roller Bearing You can consult online or call the hotline, we will provide you with detailed service.
FM-22336CA-Spherical Roller Bearing is widely used.FM-22336CA-Spherical Roller Bearing is mainly used in construction machinery, machine tools, automobiles, metallurgy, mines, petroleum, machinery, electric power, railways and other industries. The price of FM-22336CA-Spherical Roller Bearing sold by the company is reasonable, the quality is guaranteed, the service in all aspects is provided, and the customer's demand is satisfied.
